Monolayer Film Plant

Wintech Industries specializes in Monolayer Film Plants designed for a wide range of applications. These plants are known for their efficiency, quality output, and adaptability to different production requirements. They cater to the needs of industries looking for high-performance film production solutions.

Download Brochure

Silent Features

Latest technology of Mono layer blown film line with high power efficiency, compact model with greater line speed, High production with small size & Efficient for lower thickness of film

Barrier Screw with water cooled Grooved Feed technology increases the output. Extensive quality of Candle Filter increases the filtration area and provides longer life of filter to minimize down time.

Single Lip Air Ring for HMHDPE and Dule lip for LL/LD film to get optimum output capacity.

Optional Features

Hopper loader with dryer

Corona Treater

Web Aligner

Screen Changer

Gusset assly

Rotary die

Applications

Specifications Wintech Make Monolayer Plant

Models	WTMONO-40	WTMONO-55	WTMONO-60
Screw Dia (MM)	40	55	60
L/D Ratio	30:1	30:1	30:1
Main Motor (Kw)	11	22	55
Max Output (Kg/Hr) HM	40-50	85-95	-
Max Output(Kg/Hr) - LL+LD	35-40	75-85	140-150
Film Width Rang (MM)	300-600	700-1250	1000-1500
Thickness Rang (Microns)	5-50	10-120	20-150
Die Size for HM	50-75	125-175	-
Die Size for LL+LD	90-100	250	325-350
Roller Size (MM)	700	1350	1600
Max Line speed	80-100	80	80
Surface Winder	Single Station	Two Station	Two Station
